DIMENSIONAL DATA |
HEIGHT AND WIDTH DIMENSIONS |
REAR ROLL-UP OR SWING DOOR OPENING |
SIDE DOOR OPENING SINGLE PANEL |
|||||||
|
A |
B (96" Model) |
B (102" Model) |
C* |
D |
E (96" Model) |
E (102" Model) |
F |
G |
H |
|
|
GVMD79 |
96 or 102 |
95 |
101 |
85-3/8 |
79-1/8 |
96 |
94 |
73-1/4 |
40-11/16 |
70-11/16 |
|
GVMD85 |
96 or 102 |
95 |
101 |
91-3/8 |
85-1/8 |
96 |
94 |
79-1/4 |
40-11/16 |
76-11/16 |
|
GVMD91 |
96 or 102 |
95 |
101 |
97-3/8 |
91-1/8 |
96 |
94 |
85-1/4 |
40-11/16 |
82-11/16 |
|
GVMD97 |
96 or 102 |
95 |
101 |
103-3/8 |
97-1/8 |
96 |
94 |
91-1/4 |
40-11/16 |
88-11/16 |
|
GVMD103 |
96 or 102 |
95 |
101 |
109-3/8 |
103-1/8 |
96 |
94 |
97-1/4 |
40-11/16 |
94-11/16 |
|
GVMD109 |
96 or 102 |
95 |
101 |
03/08/15 |
109-1/8 |
96 |
94 |
103-1/4 |
40-11/16 |
100-11/16 |
Notes: *1.) Exterior Height Inlcudes Roof Crown But Does Not Include Body Longitudinales.
2.) Interior Width Based On Morgan Plate Panels Without Scuff.
|
BODY LENGTH DIMENSIONS |
||||||||||
|
NOMINAL LENGTH |
10 |
12 |
14 |
16 |
18 |
20 |
22 |
24 |
26 |
28 |
|
K |
10' 5-5/8" |
12' 5-5/8" |
14' 5-5/8" |
16' 5-5/8" |
18' 5-5/8" |
20' 5-5/8" |
22' 5-5/8" |
24' 5-5/8" |
26' 5-5/8" |
28' 5-5/8" |
|
L |
10' 1-1/4" |
12' 1-1/4" |
14' 1-1/4" |
16' 1-1/4" |
18' 1-1/4" |
20' 1-1/4" |
22' 1-1/4" |
24' 1-1/4" |
26' 1-1/4" |
28' 1-1/4" |
Notes: 1.) Inside Length Is Basd On Roll-Up Rear Door And Morgan Plate Front Panel Without Scuff. Add 1-1/2" If Body Has Swing Doors.
***2.) Exterior Light Is Rear Light Protector. If Body Does Not Have A Liftgate Or Dock Bumper, Add 2-1/4" To Overall Length To Cover Rear Light Protector.
|
CALCULATED WEIGHT CHART (96" MODEL WIDTH) |
||||||||||
|
BODY HEIGHT |
BODY LENGTH |
|||||||||
|
10 |
12 |
14 |
16 |
18 |
20 |
22 |
24 |
26 |
28 |
|
|
GVMD79 |
1816 |
2034 |
2251 |
2477 |
2695 |
2912 |
3129 |
3346 |
3573 |
3800 |
|
GVMD85 |
1858 |
2086 |
2303 |
2530 |
2758 |
2985 |
3202 |
3430 |
3657 |
3884 |
|
GVMD91 |
1910 |
2128 |
2356 |
2592 |
2820 |
3048 |
3275 |
3503 |
3741 |
3978 |
|
GVMD97 |
1951 |
2180 |
2408 |
2655 |
2883 |
3121 |
3349 |
3577 |
3825 |
4062 |
|
GVMD103 |
1993 |
2232 |
2470 |
2708 |
2946 |
3194 |
3422 |
3660 |
3899 |
4146 |
|
GVMD109 |
2045 |
2284 |
2522 |
2770 |
3009 |
3257 |
3495 |
3734 |
3983 |
4230 |
|
STANDARD SIDE DOOR LOCATIONS |
||||||||||
|
BODY LENGTH |
10 |
12 |
14 |
16 |
18 |
20 |
22 |
24 |
26 |
28 |
|
J |
28-3/8" |
60-3/8" |
||||||||
Notes:
1.) Foremost Location Of Side Door is 16-3/8" Fron Inside Front Panel.
2.) Door Can Be Moved Fore And Aft Of Standard Location On 2"
Increments Only.
A = Overall Width / Model Width
B = Interior Width
C = Exterior Height*
D = Interior Height
E = Rear Door Opening Width
F = Rear Door Opening Height
G = Side Door Opening Width
H = Side Door Opening Height
J = Leading Edge Of Side Door To Inside Front Of Body
K = Exterior Length of Body***
L = Inside Front Panel To Inside Rear Door Panel
Body Weight Includes: Base Body, O/H Rear Door, D.O.T. Underide, Mud Flaps, Lighting Per FMVSS 108, Mounting Kit, Morgan Plate Panels On Sides And Front, 12" Croossmember Centers and 1-1/8" Laminated Floor.
All Dimensions, Weights, And Measurements Specified Herein Are Subject To Morgan's Manufacturing Tolerances, May Change Without Notice, And May Vary Depending On Options Selected. Please Contact Morgan For Measurements For Your Particular Truck Body And Chassis Specifications.
