HEIGHT/WIDTH DIMENSIONS |
||||||
|
MODEL |
REAR DOOR OPENING |
|||||
|
OUTSIDE WIDTH |
INSIDE WIDTH |
OUTSIDE HEIGHT* |
INSIDE HEIGHT |
WIDTH |
HEIGHT** |
|
|
PVFP 72 |
79 1/2" |
78 3/8" |
84 9/16" |
72 7/16" |
71 1/2" |
66 7/8" |
|
PVFP 78 |
79 1/2" |
78 3/8" |
90 9/16" |
78 7/16" |
71 1/2" |
72 7/8" |
|
BODY LENGTH |
||
|
MODEL |
BODY LENGTH |
|
|
10' |
12' |
|
|
OUTSIDE |
10' 6 1/2" |
12' 6 1/2" |
|
INSIDE*** |
10' 1 3/4" |
12' 1 3/4" |
|
VOLUME - CUBIC CAPACITY (FT.) |
||
|
MODEL |
BODY LENGTH |
|
|
10' |
12' |
|
|
PVFP 72 |
400 |
479 |
|
PVFP 78 |
433 |
519 |
Note:
* Outside Height Dimension From Bottom Of Sidewall To Top Of Roof Crown.
** Overhead Rear Doors Protrude Into Top Of Door Opening 1" To 11/2" When In The Up Position.
*** Deduct 6.0" For Recessed Bulkhead.
All Dimensions, Weights And Measurements Specified Herein Are Subject To Morgan's Manufacturing Tolerances, May Change Without Notice, And May Vary Depending On Options Selected. Please Contact Morgan For Measurements For Your Particular Truck Body And Chassis Specifications.
