REFRIGERATED FASTRACK

SPECIFICATIONS





STANDARD FEATURES

Subframe:

4" I-beam longrails, 3" steel I-beam crossmembers on 12" centers. Glassboard subpan over crossmembers. Mylar tape between crossmembers and bottom rail.

Floor Type:

1-1/4" extruded aluminum hat type, welded watertight, including 4 drains with kazoos and built-in 6" high extruded aluminum scuff plate.

Side Walls:

Sheet & post, .040" pre-painted white aluminum sheet, with Z posts on 16" centers, 3" foam-in-place urethane insulation and 3/32" seamless glassboard liner.

Front-end Assembly:

Radius design with stainless steel corner posts; reinforcement and opening for refrigeration unit, roadside folding steps and grab handle, 3/32" glassboard liner and 4" foam-in-place urethane insulation.

Roof Assembly:

.032" one-piece aluminum roof with roof bows on 24" centers, 3" foam-in-place urethane insulation, 3/32" one-piece seamless glassboard liner and one recessed stainless steel domelight with switch in cab.

Rear Frame:

Stainless steel with built-in clearance lights protecting header, curb side and road side grab handle.

Rear Door:

1-1/2" insulated overhead door with inside safety release.

Exterior Lights:

Per FMVSS-108 specifications, including reflectors. All wiring in loom and sealed wire harness.

Insulation:

Urethane, foam-in-place – 3" sides and ceiling, 4" floor and front end.

Warranty:

Five-year limited warranty.

96" BODY WIDTH



HEIGHT

LENGTHS



12'

14'

15'

18'

20'

22'

24'

26'



85"



91"



97"



102" BODY WIDTH

HEIGHT

LENGTHS

18'

20'

22'

24'

91"

97"
