DRY FREIGHT FASTRACK

SPECIFICATIONS





STANDARD FEATURES

Subframe:

For single axle, 4" I-beam longrails, 3" steel I-beam crossmembers on 16" centers, without wheelpans
– 85" and 91" high, 12' through 16' bodies; 12" centers with wheelpans – 18' through 26' bodies and all 97", 103"
or 109" high units. Mylar tape between crossmembers and bottom rail.

Floor Type:

1-1/8" laminated hardwood, pre-undercoated rear threshold with drain holes.

Side Walls:

Prepainted white aluminum skins with Z-posts on 16" centers.

Front-end Assembly:

Aerodynamic design with contoured Poly-TuffTM corner caps, aluminum 9" top radius and 5" corner radius. Streamlined extruded aluminum body moldings, connectors and rails.

Rear Frame:

Includes light protecting header design with rain channel/drip rail diverts water and provides better clearance light protection. Painted steel threshold with drain holes. Curb side and road side grab handles.

Rear Door:

Plastic rear overhead door.

Roof Assembly:

One-piece crowned .032" aluminum sheet with Morgan's anti-snag, low profile roof bows for improved adhesive seal at all contact points.

Lighting:

Per FMVSS-108 specifications, including reflectors. One interior dome light with switch in cab. Easy maintenance, sealed wire harness on exterior lighting.

Warranty:

Five-year limited warranty.







96" BODY WIDTH













HEIGHT

LENGTHS













12'

14'

15'

18'

20'

22'

24'

26'

102" BODY WIDTH

85"

HEIGHT

LENGTHS

91"

18'

20'

22'

24'

26'

97"





97"

103"







103"

109"







109"
